Phantom
The PHANTOM is an ultra‑sensitive spy fiber‑optic microphone designed for discreet applications in environments subject to strong electromagnetic interference. With no metal components or local power supply, it is completely undetectable, operates solely on light, and can be deployed more than 10 km from its electronic unit. Its high‑sensitivity version delivers exceptional voice‑listening quality thanks to noise reduction and built‑in SD‑card audio recording.
This housing is used with an all‑plastic Evotis microphone. It provides SD‑card recording (controlled via the front‑panel button to start recording) or can be operated in VOX TRIGGER and TIME TRIGGER modes via a program stored on the SD card. The unit can also be controlled via Ethernet through the RJ45 connector.
It includes a battery that provides 24 hours of listening.
Main Features
Technology: Patented single‑fiber optic sensor
Materials: Ultem (plastic) or metal; plastic version contains no electricity or metal
Sensitivity: 150 mV/Pa at 1 kHz (94 dB SPL)
Frequency range: 150 Hz to 10 kHz (±3 dB)
SNR: 70 dB
Max pressure: 130 dB SPL
Operating distance: > 10 km without repeater
Fiber connector: E2000/APC, multimode OM1 to OM5
Conditioner dimensions: 141 × 97 × 36 mm
Power supply: µUSB 5 V (wall adapter or external battery)
Battery life: 18650 battery, 3600 mAh
Recording: microSD card (up to 32 GB), VOX or timed trigger
Use cases
Discreet, undetectable monitoring in sensitive areas
High electromagnetic‑interference environments (industrial sites, secure zones)
Security or counter‑espionage applications
Long‑distance recordings with remote access via fiber‑optic network
Scientific research requiring perfect electromagnetic isolation
